A14

April 12th, 2012

Specifications:-

Royd A14 (L)
Version L
Year of Release
Dimensions (WxHxD) 260mm x 400mm x 220mm
Recommend Amplifier Power
Sensitivity 87 dB (1W @ 1m)
Power Handling
Nominal Impedance
Drive Units 6.5" bass driver, 19mm tweeter
Crossover Frequency
Bass Resonance Frequency
Frequency Range 35 Hz to 20KHz
Port(s) Rear
Terminals Single
Finishes
Weight
Royd A14 (Mk 1)
Version Mk 1
Year of Release
Dimensions (WxHxD) 260mm x 400mm x 220mm
Recommend Amplifier Power
Sensitivity 87 dB (1W @ 1m)
Power Handling
Nominal Impedance
Drive Units 6.5" bass driver, 19mm tweeter
Crossover Frequency
Bass Resonance Frequency
Frequency Range 35 Hz to 20KHz
Port(s)
Terminals
Finishes
Weight
Royd A14 (Mk II.)
Version Mk II.
Year of Release 1991
Dimensions (WxHxD) 260mm x 400mm x 230mm
Recommend Amplifier Power 15-70W
Sensitivity 87 dB (1W @ 1m)
Power Handling
Nominal Impedance
Drive Units 6.5" bass driver, 19mm tweeter
Crossover Frequency
Bass Resonance Frequency
Frequency Range 35 Hz to 20KHz
Port(s) Sealed
Terminals Single
Finishes
Weight 8 Kg

Retailed at £199 when launched in 1991.
